GH 3500 Maintenance
Operator's manual 25
7.5 Cleaning the fuel dirt separator
f Place the machine upright on a flat surface.
f Close the fuel tap (1).
f Remove any dirt around the fuel dirt separator (2).
f Place a container under the fuel dirt separator to catch the fuel.
f Use an open-end wrench to remove the fuel dirt separator and empty it into
the container.
Note: Avoid spilling fuel. Remove any spilt fuel immediately.
f Clean the fuel dirt separator with gasoline.
f Insert the fuel dirt separator with the seal and use a torque wrench to tighten
it to 5 Nm.
Check for leaks:
f Open the fuel tap.
There must not be any leaking fuel.
Note: Dispose of the contents of the container in accordance with the appli-
cable regulations.
DANGER
Danger of fire and explosions by fuel!
Any fuel in open containers can ignite and cause severe burns.
Do not smoke, no open fire!
2
1
