Operation HI400HD D / HD G
4.7 Adjusting the Handle Height
Overview
Your machine is equipped with a manual transport handle. The handle height can
be adjusted to suit the operator’s preference.
Procedure
Perform the procedure below to adjust the handle height.
1. Loosen, but do not remove, the two adjusting knobs (a) on the handle.
2. Grasp the handgrips (b) and slide the handle up or down to one of the three
detent positions in the handle slots.
3. When the handle is in the desired position, tighten the two adjusting knobs.
wc_gr007767
a
a
b
