Technical Data HI400HD D / HD G
9 Technical Data
9.1 Machine
Model HI400HD D HI400HD G
Units
Gross burner heat input BTU/hr (kW) 412,682 (120.8) NG: 380,548 (111.4)
LP: 334,700 (98)
Net heat output BTU/hr (kW) 341,288 (99.9) NG: 329,174 (96.4)
LP: 289,515 (84.8)
Air flow cfm 3015 3015
Fuel consumption L/hr (gph) 11.2 (2.97) —
Fuel consumption
—Natural gas (NG)
—Liquid propane (LP)
m
3
/hr (cfh)
L/hr (gph)
—
10.1 (355.97)
13.8 (3.65)
Fuel nozzle size L/hr (gph) 7.6 (2.0) (80W) —
Fuel nozzle size mm (in.) — 3 x 2.8 (12 x 0.11)
Efficiency % 82.7 82.8
Noise level at 1 m dB (A) 76 74
Power requirement VAC/Hz 120/60 120/60
Electrical current (@15°C) Ampere 13 11.8
Weight (no fuel) kg (lb) 206.8 (456) 225.4 (497)
Height mm (in.) 1308 (51.5) 1105 (43.5)
Length mm (in.) 2134 (84) 2134 (84)
Width mm (in.) 838 (33) 838 (33)
Flue diameter mm (in.) 152.4 (6) 152.4 (6)
Fuel tank capacity L (gal) 216.1 (57.1) —
Fuel pressure psi (bar)
Stage I: 181 (12.5)
Stage II: 217 (15)
—
Fuel supply pressure
—Natural gas
—Liquid propane (LP)
WC (Pa)
— Min 7, Max 10
Min 8, Max 13
Burner pressure
—Natural gas
—Liquid propane (LP)
WC (Pa)
— 6.40 (1600)
6.52 (1630)
Air damper setting number 1.5 3
Static air pressure limit WC (Pa) 0.60 (150)
