HI400HD D / HD G Operation
4.18 Flex Ducting Options
Refer to the chart below for the maximum allowable return and supply duct lengths
for your machine.
NOTICE: Do not exceed the maximum total lengths specified in the chart.
Exceeding these lengths, or blocking any of the duct openings, constricts the air
flow through the machine and may cause a high-temperature shut-down fault.
Note: Return ducting information is based on typical work applications. Contact
your Wacker Neuson dealer for more information on return ducting configurations.
MODEL SUPPLY DUCTING RETURN DUCTING
Supply
Duct
Adapter
Length of
each duct
section (ft)
Maximum duct
sections per
opening
Total
length
needed
Return
Duct
Adapter
Typical number
of 25 ft duct
sections
Total
length
needed
Qty Length
AB XHD
HI770
1 x 20 in. 25 8 200 ft 200 ft 1 x 20 in. 1 25 ft
1 x 16 in. 25 6 150 ft 150 ft
2 x 12 in. 25 3 75 ft 150 ft
HI110 1 x 12 in. 25 1 25 ft 25 ft Return ductwork not available.
HI200 2 x 12 in. 25 2 50 ft 100 ft
1 x 14 in. 25 1 25 ft 25 ft
HI300 1 x 16 in. 25 2 50 ft 50 ft
HI300 HD 2 x 12 in. 25 1 25 ft 50 ft
HI400 D/G 1 x 20 in. 25 4 100 ft 100 ft 1 x 20 in. 1 25 ft
2 x 16 in. 25 2 50 ft 100 ft
3 x 12 in. 25 1 25 ft 75 ft
HI750
HI900
HI1000
2 x 20 in. 25 6 150 ft 300 ft 2 x 20 in. 1 50 ft
3 x 20 in. 25 9 225 ft 675 ft
3 x 16 in. 25 3 75 ft 225 ft
4 x 12 in. 25 1 25 ft 100 ft
HIF690 1 x 20 in. 25 4 100 ft 100 ft 1 x 20 in. 1 25 ft
1 x 16 in. 25 2 50 ft 50 ft
2 x 12 in. 25 1 25 ft 50 ft
HIF600 1 x 20 in. 25 6 150 ft 150 ft 1 x 20 in. 1 25 ft
1 x 16 in. 25 4 100 ft 100 ft
2 x 12 in. 25 4 100 ft 200 ft
HIF1200 2 x 20 in. 25 8 200 ft 400 ft 1 x 20 in. 1 25 ft
2 x 16 in. 25 2 50 ft 100 ft
4 x 12 in. 25 1 25 ft 100 ft
