Maintenance PT 3 / PT 3A / PT 3H
44 wc_tx001776gb.fm
5.12 Fuel Filter (Hatz)
See Graphic: wc_gr000031
Fuel filter maintenance intervals depend on the purity of the diesel fuel
used. If operating the machine with dirty fuel, perform this operation at
250 hours.
When working on the fuel system, keep the work area clean. Make
sure no dirt reaches the fuel. Dirty fuel may damage the engine.
Fire hazard. Diesel fuel is flammable and must be treated with care. Do
not smoke when working with diesel fuel. Do not expose diesel fuel to
sparks or open flames.
5.12.1 Remove the fuel tank cap (a) and pull the fuel filter (b) and fuel hose
out of the fuel tank.
5.12.2 Pull the fuel hose from the fuel filter.
5.12.3 Install a new fuel filter onto the fuel hose.
5.12.4 Place the fuel filter and fuel hose into the fuel tank and install the fuel
tank cap.
Note: Bleeding of the fuel injection system takes place automatically.
WARNING
