4-28
BA TH412 * 06/2017 * 4512_4-3_Warnleuchten_en.fm
4 Putting into operation
Warning light “Engine oil pressure” (red)
Illuminates when the key in preheating start switch is
in position 1, but goes out as soon as the engine runs.
Illuminates if the engine oil pressure is too low.
In this case:
1. Stop the vehicle.
2. Stop the engine immediately and check the oil level.
➥
Engine lubrication system on page 7-32
Forward travel direction indicator light (green)
Illuminates if forward machine travel is enabled.
➥
Changing the travel direction on page 5-11
Reverse travel direction indicator light (green)
Illuminates if reverse machine travel is enabled.
➥
Changing the travel direction on page 5-11
