Wacker Neuson Telehandler TH412

Operation 5
BA TH412 * 06/2017 * 4512_5-9_Arbeitshydraulik_en.fm 5-29
Loader unit control lever
The control lever 4 controls the work movements of the
loader unit. Control lever is located on the right of the
operator seat.
Loader unit
• Move the control lever 4 toward H:
➥ The loader unit is raised. The telescopic boom is
extended.
• Move the control lever 4 toward S:
➥ The loader unit is lowered. The telescopic boom is
retracted.
Attachment
• Move control lever 4 toward E.
➥ The attachment tilts in.
• Move control lever 4 toward A.
➥ The attachment tilts out.
Information
The control lever automatically returns to the middle
position as soon as it is released.
Fig. 63
A
H
E
S
4
