Wacker Neuson Telehandler TH412 User Manual

5-56 BA TH412 * 06/2017 * 4512_5-11_Arbeitsbetrieb_en.fm
5 Operation
Safe load indicator
CAUTION
Accident hazard due to tipping over of machine!
The safe load indicator only gives a warning in the event
of insufficient stability in the longitudinal direction and
toward the front. Lateral loads are not indicated by the
safe load indicator.
Always pay attention to the stability display 3 at the upper
right in the cabin while working. The display of the safe
load indicator indicates machine stability as a function of
the raised load. The safe load indicator gives visual and
acoustic signals.
1. Green up to 40%: There is no risk of the machine
tipping over, all travel and work movements can be
continued.
• Green up to 85%: There is a slight risk of the machine
tipping over, pay attention to the display of the safe
load indicator for further travel and work movements.
2. Orange: There is an increased risk of the machine
tipping over. Perform further travel and work
movements with caution.
3. Red: There is an imminent risk of the machine tipping
over!
- With an extended boom: the overload protection is
active.
- With the telescopic boom retracted: Immediately
stop the work movement currently being carried out.
Retract the telescopic boom or lower the loader unit.
40%
85%
Fig. 82
3
