Maintenance 7
BA TH412 * 06/2017 * 4512_7-8_Motoroel_en.fm
7-33
Preparations:
1. Park the machine on firm, level and dry ground.
2. Apply the parking brake.
3. Lower the loader unit to the ground.
4. Stop the engine.
➥ Wait one minute.
5. Open the engine cover.
Checking the engine oil level:
1. Pull out the engine oil dipstick 1 (
Fig. 142).
2. Wipe the engine oil dipstick with a clean and lint-free
cleaning cloth.
3. Re-insert the engine oil dipstick.
4. Pull the engine oil dipstick back out again.
5. Check the engine oil level.
➥ The engine oil level must be between the “Min” and
“Max” marks.
6. Re-insert the engine oil dipstick.
