Technical data 9
BA TH412 * 06/2017 * 4512_9_Tech_Daten_en.fm
9-17
Item Designation mm (in)
M1* Max. tilt-out height with extended boom (bucket) 3631 142.95
M2* Max. tilt-out height with retracted boom (bucket) 2417 95.28
N Max. reach with M1 542 21.34
N1 Max. reach with extended boom (pallet forks) 2279 89.72
N2 Max. reach with retracted boom (pallet forks) 920 36.22
O* Scraping depth 94 3.70
P* Overall width 1560 61.42
Q* Track 1296 51.02
S* Ground clearance 306 12.05
T Max. radius (bucket) 3517 138.46
T1 Max. radius (pallet forks) 3409 134.21
U* Radius at outer edge 2722 107.17
V Inner radius 951 37.44
X Roll back angle at max. lift height ° 52
Y Max. tilt-out angle °31
Z Roll back angle at ground ° 44
Dimensions with tires 10.0/75-15.3 AS
All height dimensions refer to the static radius of the wheels.
*Dimensions differ if other tires or reversed wheel rims are used
