Technical data 9
BA TH412 * 06/2017 * 4512_9_Tech_Daten_en.fm 9-19
Item Designation mm (in)
A
Overall length with standard bucket 3911 153.98
Overall length with pallet forks 4038 158.98
B Length incl. quickhitch 2941 115.79
C Center of axle to attachment pivot 450 17.72
D Wheelbase 1920 75.59
E Rear overhang 391 15.39
F* Height above cabin/protective roof for operator 1941 76.42
H* Seat height 953 37.52
J*
Total work height (bucket) 5218 205.43
Total work height (pallet forks) 4990 196.46
K* Max. height of attachment pivot 4531 178.39
L1*
Load-over height with extended boom (bucket) 4151 163.43
Pallet height with extended boom (pallet forks) 4386 172.68
L2*
Load-over height with retracted boom (bucket) 2937 115.63
Pallet height with retracted boom (pallet forks) 3072 120.95
Dimensions with tires 10.0/75-15.3 AS
All height dimensions refer to the static radius of the wheels.
*Dimensions differ if other tires or reversed wheel rims are used
