Technical data
VP 13.3
45
[en] | 02/2020 | 5100056064 | VP | Operator’s manual
Type VP1550Aw VP2050A
Gradeability [%] 36,4 36,4
Length (drawbar in working position) [mm] 1035 1035
Width [mm] 503 503
Height [mm] 940 940
Underclearance [mm] 583 552
Operating weight [kg] 102 100
Nominal power** [kW] 3,6 3,6
Rated speed [1/min] 3600 3600
Exciter oil quantity [l] 0,25 0,25
Exciter oil type 75W-90 API GL-4 75W-90 API GL-4
Operating temperature range [°C] -15 - +40 -15 - +40
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA
[dB(A)]
91 94
Sound power level LWA, measured [dB(A* 101 103
Sound power level LWA guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 2,7 3,6
Measurement uncertainty of the total vibration
value ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
Type VP2050Aw VP1550Aw
Material number machine 5100029052 5100051526
Material number engine 5100045995 5100045995
Centrifugal force [kN] 20 15
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 750 750
Flow [m/min] 25 25
Gradeability [%] 36,4 36.4
Length (drawbar in working position) [mm] 1035 1035
Width [mm] 503 503
Height [mm] 940 940
Underclearance [mm] 583 583
Operating weight [kg] 110 102
Nominal power** [kW] 3,6 3.6
Rated speed [1/min] 3600 3600
Exciter oil quantity [l] 0,25 0.25
Exciter oil type 75W-90 API GL-4 75W-90 API GL-4
Operating temperature range [°C] -15 - +40 -15 - +40
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA
[dB(A)]
94 91
13
