35
Power Adaptor
Input voltage: 100 to 240 VAC, 50/60 Hz
Output voltage: 12 VDC, 3.3 A
Pen
Pen tip travel: 0.1 mm (0.004 in) or less
Eraser tip travel: 2 mm (0.08 in), approximately
Physical dimensions, weight: 14.0 x 159.0 mm, 16g (0.63 x 6.26 in, 0.56 oz)
Side switch type: Rocker switch
Tablet
Reading technology: Electromagnetic reasonance method
Active area: 304.1 x 228.1mm
Resolution:
20
lpmm (0.05mm) max.
Accuracy: +/-0.5mm, four corners ( 20 mm wide, 80 mm
long from each corner of four "L" shaped areas)
to be +/-2.0mm
Maximum reading height: 5mm
Maximum report rate: 100 points/sec., max
Pressure levels: 512 levels
Communication interface: USB or RS-232C serial
