17
Stand
The stand can be used to
adjust the tilt angle of the unit
from low (16°from horizontal)
to high (72° from horizontal).
Stand Adjustment Lever
Pull this lever to adjust the
stand. Release the lever to
lock the stand in place.
Be sure to adjust the tilt angle of the stand to the low tilt position
before packaging DTI-520. If you do not close the stand, the
notched mechanism may be damaged during transportation and
storage. Do not lift the unit by the stand; this may damage the
stand mechanism. When lifting or moving the unit, always do so
by grasping the main body casing.
Be careful to avoid
catching your finger in
the gap of the movable
portion of the stand.
CAUTION
Rear View
Important
To Next Page
