34
General Specifications
Physical dimensions (WxDxH): 344x300x49mm (excluding the stand)
Weight: 4.0kg (including the stand)
Main Unit input Voltage: DC12V
Power consumption: 23W or less (DC12V)
Operating temp. & humidity: 5 to 35 deg. C, 20 to 80%RH (non condensing)
Storage temp. & humidity:
-
10 to 60deg. C, 20 to 90%RH (non condensing)
(maximum storage humidity is 38% at 60 deg.C,
and maximum storage temperature is 42 deg. C at
90% humidity)
LCD Display
Display: a-Si TFT active matrix LCD
Screen size: 15 inch
Resolution (75Hz Max.) 1024x768 pixels (XGA), 800x600 pixels (SVGA),
640x480 pixels (VGA)
Pixel pitch: 0.297(W) x 0.297(H)mm
Color depth: 253 levels: 16,194,277 colors
Signal Inputs: Analog RGB
Synchronous frequency: Horizontal 30 to 56.5kHz,
Vertical 45 to 75Hz(45Hz to 70Hz / XGA mode)
All scan modes are non-interlaced.
Plug and Play DDC2B
On a TFT liquid crystal display, a very small number of pixels may be permanently
illuminated or not illuminated at all. This does not mean that the display is defective.
