PerfectView CAM50 Safety and installation instructions
25
Please observe the following instructions:
To prevent short circuits, always disconnect the negative terminal of the
vehicle’s electrical system before working on it.
If the vehicle has an additional battery, its negative terminal should also
be disconnected.
Insufficient supply line connections could result in short circuits which
– Cause cable fires
– Trigger the airbags
– Damage electronic control devices
– Cause electric functions to fail (indicators, brake light, horn, ignition,
lights)
When working on the following lines, only use insulated cable lugs,
plugs and tab sleeves:
– 30 (direct supply from positive battery terminal)
– 15 (connected positive terminal, behind the battery)
– 31 (return line from the battery, earth)
– 58 (reversing light)
Do not use porcelain wire connectors.
Use a crimping tool (fig. 1 10, page 2) to connect the cables.
When connecting to supply line 31 (earth), screw the cable
– To the vehicle’s earth bolt with a cable lug and a gear disc or
– To the sheet metal body work with a cable lug and a self-tapping
screw.
Ensure that there is a good earth connection.
When the negative terminal of the battery is disconnected, all data stored in
the volatile memories will be lost.
The following data must be set again, depending on the vehicle
equipment options:
– Radio code
– Vehicle clock
–Timer
– On-board computer
– Seat position
You can find instructions for making these settings in the appropriate
operating instructions.
_CAM50.book Seite 25 Montag, 7. Mai 2012 3:12 15
