PerfectView M5L, M7L, M7LX Accessories
27
4 Accessories
Available as accessory (not included in scope of delivery):
5 Intended use
The LCD monitors PerfectView M5L, M7L and M7LX are monitors which are primarily in-
tended for use in vehicles. They can be used together with cameras
(e.g. a reversing video system) or other video sources.
The LCD monitors are designed for use in all vehicles.
6 Technical description
6.1 Function description
The LCD monitor is a monitor for the connection of cameras (e. g. reversing video sys-
tems) or other video sources (e. g. TV set). It is possible to switch back and forth between
video sources.
The monitor features control cables which allow the cameras to be activated automatical-
ly.
To secure it and connect the power, slide it onto the monitor bracket. The Easylink system
allows the monitor to be easily removed from the monitor bracket. It can therefore be re-
moved to protect it from theft, or for use in several trucks in a fleet (fleet solution).
The monitors M5L and M7L can operate up to two cameras.
The monitor M7LX can operate up to three cameras. Alongside the usual controls, the
three cameras can be switched consecutively in automatic mode. This monitor also fea-
tures a distance indicator in the display which is activated automatically when the reverse
gear is engaged.
A further video source can also be connected to the monitors, e.g. a reversing camera on
the trailer (trailer operation). This additional video input has signal detection: when a video
source is connected to this video input, video input C1 is automatically deactivated (e.g.
the reversing camera on the tractor) and the image from the additional video input is dis-
played instead.
The brightness of the monitor adapts automatically to the ambient light.
Designation Item no.
Monitor bracket with support for M5L 9102200049
Monitor bracket with support for M7L 9102200050
_M5L_M7L_M7LX.book Seite 27 Montag, 7. Mai 2012 10:59 10
