PerfectView CAM50 Mounting the camera
33
➤ Drill a hole of Ø 16 mm near the camera.
➤ Deburr all drill holes that have been made in the sheet metal and apply
rust-protection.
➤ Place cable sleeves in all sharp edged ducts.
Mounting the camera
A
NOTICE! Risk of damage!
Only use the screws supplied to mount the camera in the camera
bracket. Longer screws will damage the camera.
➤ Push the camera into the camera bracket.
➤ Attach the camera loosely with the two screws M3 x 6 mm in the slots
(fig. e, page 5).
➤ Align the camera provisorily so that the lens is at an angle of approx. 50°
to the perpendicular axis of the vehicle (fig. f, page 6).
A
NOTICE! Risk of damage!
Never mount the camera without the camera guard.
➤ Push the camera guard over the camera (fig. g, page 6)
Connecting the camera
I
NOTE
Lay the camera cable so that should you need to remove the
camera, you can access the plug connection between the
camera and the extension cable easily. This considerably
eases dismantling work.
To minimise corrosion in the plug, apply a small amount of
grease – such as pin grease – inside the plug.
Additional extension cables are available on request
(see “Accessories” on page 27).
➤ Guide the camera cable into the vehicle interior.
➤ Insert the plug of the camera cable into the socket of the extension cable.
➤ Screw on the plug connections of the connecting cables to protect against
water penetration (fig. h, page 6).
