Mounting the LCD monitor PerfectView M5L, M7L, M7LX
30
Choosing the installation location
➤ Place the monitor and the mounting rail on the monitor bracket (fig. a A, page 6).
➤ Place the monitor bracket and the mounting rail onto the support base and secure it
using the knurled nuts (fig. a B, page 6).
➤ Position the monitor and the attached monitor bracket provisionally.
➤ Mark the outlines of the corners of the support base on the dashboard.
➤ Unscrew the support base from the monitor holder.
I
NOTE
You can fasten the support base using adhesive or screws.
Sticking the monitor bracket onto the dashboard (fig. b A, page 6)
➤ Remove the film from under the support base.
➤ Stick the support base to the position of your choice.
Screwing the monitor bracket onto the dashboard (fig. b B, page 6)
➤ Hold the support base within the outlines marked beforehand.
➤ Mark four different drilling points.
➤ Drill a hole of 2 mm at each of the points marked beforehand.
➤ Screw the support base on using 4 x 20 mm self-tapping screws.
Fastening the monitor
➤ Place the monitor and the mounting rail onto the support base and secure it using the
knurled nuts (fig. a, page 6).
