Mounting the camera PerfectView CAM50
30
8 Mounting the camera
8.1 Tools required
For installation and assembly you will require the following tools:
Drill bit set (fig. 1 1, page 2)
Drill (fig. 1 2, page 2)
Screwdriver (fig. 1 3, page 2)
Set of ring or open-ended spanners (fig. 1 4, page 2)
Measuring ruler (fig. 1 5, page 2)
Hammer (fig. 1 6, page 2)
Centre punch (fig. 1 7, page 2)
To make and test the electrical connection, the following tools are required:
Diode test lamp (fig. 1 8, page 2) or voltmeter (fig. 1 9, page 2)
Insulating tape (fig. 1 11, page 2)
Cable bushing sleeves, if necessary
To fasten the cables you may require additional cable binders.
8.2 Mounting the camera
!
CAUTION!
Select a location for the camera and attach it so securely that
it cannot under any circumstances fall off and injure bystanders
(e.g. by being knocked off by branches brushing over the roof of the
vehicle).
I
NOTE
If installing the camera alters the vehicle height or length specified
in the vehicle documents, your vehicle must be inspected by the
appropriate authorities.
Make sure that you are in possession of documents verifying that
your vehicle has passed this inspection.
