PerfectView CAM50 Notes on the electrical connections
29
Please observe the following instructions:
As far as possible, use original openings or alternative openings for the
connecting cable duct, e.g. the paneling edges, ventilation grilles or blank
panels. If no openings are available, you must drill holes for the cables.
Check beforehand that there is sufficient room for the drill head to come
out on the other side.
Wherever possible lay cables inside the vehicle, as they are better
protected inside than outside the vehicle.
If you do need to lay a cable outside the vehicle, ensure that it is well
secured (use additional cable ties, insulating tape, etc.).
To prevent damage to the cables, when laying them ensure that there is
sufficient distance to hot or moving vehicle components (exhaust pipes,
drive shafts, light systems, fans, heater etc.). Use corrugated piping or
other protective materials to protect against mechanical wear.
Screw on the plug connections of the connecting cables to protect against
water penetration (fig. h, page 6).
When laying electric connections, ensure that
– They are not kinked or twisted
– They do not rub on edges
– They are not laid in sharp edged ducts without protection (fig. 3,
page 3)
Attach the cables securely in the vehicles to prevent tripping hazards.
Use cable binders, insulating tape or glue the cables in place.
Protect every through-hole made in the bodywork against water pene-
tration, e.g. by using a cable with a sealant and by spraying the cable and
the the cable sleeve with sealant.
I
NOTE
Do not start sealing the through-holes until all installation work has
been finished for the camera, and the required cable lengths have
been established.
