Technical description PerfectView CAM50
28
!
WARNING!
Risk of injury!
Since rear view systems are designed merely as an additional aid
for reversing, it does not relieve you of the duty to take proper
care when reversing.
6 Technical description
The camera with integrated microphone, which is encased in aluminium
housing, transmits image and sound to a monitor via a cable. The built-in
infrared LEDs improve night vision.
The camera transmits the image as if you are looking in the rear mirror.
The camera consists of the following main elements:
7 Notes on the electrical connections
7.1 Laying cables
A
NOTICE! Risk of damage!
To prevent damage, when drilling ensure that there is sufficient
space on the other side for the drill head to come out.
Cables and connections which are not properly installed will
cause malfunctions or damage to components. Correct installa-
tion of cables and connections is the basic prerequisite for last-
ing and trouble-free operation of the retrofitted components.
The cables may not be exposed for long periods to solvents
such as benzine, as the solvents can damage the cable.
No. in
fig. 9, page 4
Description
1 6-pin connection cable
2 Infrared LEDs
3 Microphone (back side)
_CAM50.book Seite 28 Montag, 7. Mai 2012 3:12 15
