Mounting the LCD monitor PerfectView M5L, M7L, M7LX
32
Observe the following instructions when laying the connection cable:
Feed the connection cable through existing ducts or other openings where possible,
e. g. ventilation grilles. If no suitable ducts or openings are available you will need to
drill a hole of 20 mm. Check beforehand that there is sufficient space on the other
side for the drill head to emerge (fig. 2, page 3).
To prevent damage to the cables, when laying them ensure that there is always a
sufficient interval to vehicle components which can become hot (lights, heaters, ven-
tilators etc.).
Wrap insulating tape around every connection on the cable (even inside the vehicle).
When laying the cables, make sure:
– they are not kinked or twisted
– they do not rub on edges
– they are not laid in sharp-edged ducts without protection (fig. 3, page 3).
Connecting the monitor as a reversing video system (fig. d, page 7)
➤ Lay the connection cable for the monitor bracket on the dashboard.
➤ Insert the plug of the monitor cable (2) into the socket (4) of the connection cable (3).
A
NOTICE! Risk of damage
Make sure the polarity is correct when connecting to a voltage source.
➤ Connect the red and black cables of the connection cable to a suitable voltage sup-
ply:
– Connect the red cable (5) to terminal 15 (ignition).
– Connect the black cable (6) to terminal 31 (earth).
➤ If the monitor is to be activated when reverse gear is selected, connect the green ca-
ble (8) to the positive cable of the reversing light.
I
NOTE
If voltage is present in the green cable (8), the reversing camera will be activated
automatically. The reversing camera has priority.
➤ If the monitor is to be activated e. g. when the indicator is flashing, connect the fol-
lowing control cable to a positive cable of the indicator:
– M5L, M7L: white cable (8)
– M7LX: white cable (8), blue cable (13)
I
NOTE
If voltage is present in this control cable, the following video input will be activat-
ed:
M5L, M7L: video input C2
M7LX: video input C2, video input C3
This control cable is used as a signal cable for the activation e. g. of a side camera when
an indicator is flashing.
_M5L_M7L_M7LX.book Seite 32 Montag, 7. Mai 2012 10:59 10
