Power and Material Controls
Spray performance will depend upon a number of
factors: material thickness, air power, spray pattern
selected, and material ow. Testing dierent
variations of the control settings will help you
achieve the desired results. See descriptions and
suggested Power and Material Settings Guide below
to help with your project.
X-Boost™ Power Dial
The X-Boost™ power dial adjusts the level of air
pressure produced by the turbine. The X-Boost™
power dial is factory-set at maximum out of the box.
• A high air power level will result in faster
coverage and a smoother nish with thicker
materials.
• Lowering the air
power
will result in larger
drops of material being sprayed from the gun,
and will create a slightly rougher nish.
+
-
Tip: The thicker the material you are spraying,
the higher the turbine
power
you will need. Thick
materials will spray on coarse and smooth out as it
dries.
Tip: For ne-nish work with thinner materials, you
may want to decrease the air
power
. Spraying a
thinner material at high air
power
will result in more
overspray. Overspray is sprayed material that does
not stick to the spray surface and bounces back.
Material Flow Control
The material ow control determines the amount of
spray material that is sprayed from the spray gun.
Set the material ow by turning the knob on the
body of the spray nozzle (iSpray) or the knob on the
back of the trigger (Control Finish).
iSpray Control Finish
• For thicker materials, it is recommended that
you start with the material ow setting (5) and
then gradually increase the ow to suit your
particular spraying needs.
• For thinner materials, it is recommended that
you start with a low material ow setting (1),
and then gradually increase the ow to suit
your particular spraying needs.
• The higher the ow setting, the quicker you will
have to work in order to avoid drips and sags in
your spray pattern.
Tip: Spraying with the control set too high will
result in a spray pattern that runs and sags (too
much material).
Tip: Spraying with the control set too low will result
in a spray pattern that does not cover (not enough
material).
Tip: To ensure desired results are achieved with the
controls, test your spray pattern on the spray poster
or a scrap piece of wood or cardboard.
Power and Material Settings Guide
Coating
iSpray Nozzle Control Finish Nozzle
Material
Flow
Air Power Material
Flow
Air Power
Transparent / semi-transparent stains,
sealers
1-3 3-4 Med/Heavy min-3
Lacquers (water based) 1-4 3-4 Med/Heavy min-3
Solid stains 3-7 4-7 Med 4-7
Polyurethane 5-8 4-7 Med/Heavy 4-7
Oil enamels 9-10 6-9 Heavy 6-9
Latex paints plus primers, Latex paints 9-10 7-max Heavy* 7-max*
Oil or latex primers 9-10 7-max Heavy* 7-max*
* Thinning may be necessary to speed up spraying.
