P_00889
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
15.27 HICOATED PUMP F
Pos K Quantity Order No. Designation
241624 HiCoat-ED pump F
1
1 241229 Collector nozzle low air
2 1 241479 Hose sleeve
3 1 241466 Union nut
4 1 241930 Air nozzle
5 2 241460 Spring check valve
7 1 9970149 Sealing ring
8 1 9999047 Quick-release plug
9 1 9999048 Quick-release socket
10 1 9970150 Sealing ring
11
2 9974023 O-ring, electrically conductive
Wearing part
Not part of the standard equipment, but available as a special accessory
Only available as a set
