47
PXM
1 4 5 6
891112
P_02524
7
3
13 10
2
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
7.3 TOUCH SCREEN OPERATION STANDARD EQUIPMENT
1 Peristaltic pump On/O
2 Exhaust system status
3 Ultrasonic sieve device On/O
4 Language selection
5 Reciprocator Up/Down
6 Manual/automatic mode
7 Illumination On/O
8 Button for clamping the tank (box, powder container)*
9 Replenishing fresh powder (manual, time-controlled) On/O
10 Workstation/vibrator uidization On/O
11 Automatic fresh powder supply On/O (only in automatic mode)
12 Throttle valve Open/Closed
13 BigBag fresh powder On/O , as an alternative to the fresh powder supply from the box
* Additional actuation of the safety switch for two-handed operation below the touch
screen required
Home page
Auto
Cleaning
Settings
Alarm
Manual
7.3.1 EQUIPMENT WITH FINAL FILTER
