OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
5.8 EXPLANATION OF THE SCREEN PAGE NUMBERS
3 - 2 - 3
Button number in function bar 2
Button number in function bar 1
Button number in the menu bar
Function bar 1
Function bar 2
"Scroll forwards/backwards" buttons
Menu bar
Page number
The screen pages are numbered from top to bottom (1-4) in the menu bar and from left to
right (1-5) in the function bar.
Home page
Cleaning
Settings
Alarm
Service
RP supply
Work station
FP
supply
RP
supply
Diagnosis
Message recovery system [sec]
MP
operation
MP
cleaning
Settings System
Exhaust
system
Operating mode
Standard
Duration Eco
No Yes
Standard
RP break time [sec]
RP feed time [sec]
