42
OPERATING MANUAL
VERSION 05/2017 ORDER NUMBER DOC 2354920
SPRINT XE
7.3 FACTORY SETTING RECIPE NOS. 1–4
The following set values are stored in recipe Nos. 1–4 in the factory.
Recipe no. Designation Characteristic High voltage
[kV]
Current limitation
[μA]
Characteristic
curve
Total air
[m³/h]
Feed air
[%]
Atomizing air
[m³/h]
P01 Flat part
High surface
coverage
90 80 Standard 4.0 70 0.1
P02
Second
coating
Avoidance of
spraying back
50 20 Soft 3.6 57 0.1
P03 Pro le part
Penetration
and reduced
build-up of
edges
70 40 Soft 3.6 50 0.1
P04 Double click
Small
components
80 20 Soft 3.6 45 0.1
P05–50 variable individual 80 100 Standard 4.5 80 0.1
Notes:
Under normal conditions, metallic powder can be processed well using recipes Nos.1–4.
When operating the system with a Tribo gun, the values for total air, powder ow and Tribo air must be adjusted
accordingly and saved.
With the 3 L tank variant, the values must also be adjusted individually and saved.
