Page #20 background imageLoading...
Page #20 background image
12
W 690 Flexio Extra Spray Kit
AUS
17. Cleaning the Gravity spray attachment
1) Unscrew the container cover and pour any remaining coating material back into the
original container.
CAUTION! Never clean seals, diaphragm and nozzle or air holes of the spray gun with metal
objects.
The ventilation hose and diaphragm are only solvent-resistant to a limited
extent. Do not immerse in solvent, only wipe.
2) The unit may only be operated with an undamaged diaphragm (Fig. 18, D). If any
paint has penetrated to the ventilation hose, check and clean the membrane (see the
Maintenance chapter).
3) Unscrew the union nut (Fig. 24, 1) and remove the air cap (2) and nozzle (3).
Clean the air cap, nozzle seal and nozzle with a brush and solvent or water.
4)
Clean the outside of the spray gun and container with a cloth soaked in solvent or
water.
Assembly
Attention! Never operate the device if the nozzle seal is either damaged or
missing. If the nozzle seal is either missing or damaged liquids can enter
the device and increase the risk of an electric shock.
1)
Push the nozzle seal (g. 25, 4) over the needle (5); the groove (slot) should point
towards you.
2) Put the nozzle (g. 25, 3) onto the gun body and nd the correct position by turning it.
3) Put the air cap onto the nozzle and tighten it using the union nut.
4) Place the container seal from below on the suction tube and slide it over the collar,
while turning the container seal slightly.
5) Insert the suction tube with container seal in the gun body.
In order to mount the gun more easily apply lubricating grease (enclosed) liberally
to the O-ring at the gun front part. (Fig. 27, 5)
18. Maintenance
Air lter
WARNING! Never operate the machine without the air filter;
dirt could be sucked in and interfere with the function of the
machine. Check the air filter after each use for contaminants.
Disconnect plug before changing parts.
Replace the air lters depending on soiling. Unplug the power plug. Open the cover of

Other manuals for WAGNER W 690 Flexio

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the WAGNER W 690 Flexio and is the answer not in the manual?

WAGNER W 690 Flexio Specifications

General IconGeneral
Weight2.4 kg
TechnologyHVLP
Spray Width250 mm
Frequency50 Hz
Container Capacity0.9 l
Paint container volume0.9 l
Voltage230 V
