W 690 Flexio Extra Spray Kit
AUS
Malfunction Cause Remedy
Too much fog of
coating material
(Overspray)
•
Distance to the object too large
•
Too much coating material applied
•
Amount of air too high
➞ Reduce distance
➞ Reduce the material
volume
➞ Turn the air volume
control to the left (-)
Paint in the
ventilating hose
•
Diaphragm soiled
•
Diaphragm defective
➞ Clean the diaphragm
➞ Replace the diaphragm
Poor covering
capacity on the
wall
•
Spray material is too cold
•
Highly absorbent surface or paint
with poor covering capacity
•
Distance too large
➞ The material you are
spraying should be at
room temperature
➞ Cross spray (Fig. 16)
➞ Closer to the object
24. Technical Data
Technical Data
Max. viscosity:
Interior wall paint
Varnish paints, glazes, etc.
4000 mPas
60 DIN-s
Max. ow rate:
Interior wall paint
Varnish paints, glazes, etc.
400 ml/min
150 ml/min
Power source 240 V
~
, 50 Hz
Power consumption 630 W
Double insulation
Sound pressure level* 79 dB (A); Uncertainty K = 4 dB
Sound pressure output* 92 dB (A); Uncertainty K =4 dB
Oscillation level* < 2.5 m/s²; Uncertainty K = 1.5 m/s²
Air hose length 3.5 m
Weight approx. 3.3 kg
* Measured in accordance with EN 60745-1
Information about the oscillation level
The specied oscillation level has been measured according to a standard test
procedure and can be used to compare against electric tools.
The oscillation level is also for determining an initial assessment of the vibrational strain.
Attention! The vibration emission value can dier from the specied value when the

WAGNER W 690 Flexio Specifications

General

Weight	2.4 kg
Technology	HVLP
Spray Width	250 mm
Frequency	50 Hz
Container Capacity	0.9 l
Paint container volume	0.9 l
Voltage	230 V
