WAGO I/O-SYSTEM 750 Quick Start

12 • Quick Start
Starting up the Bluetooth® Modules
WAGO-I/O-SYSTEM 750
I/O Modules
13. Give the device a name (UserFriendlyName); e.g., "MyMaster".
14. Mark the MAC address and choose the value "Yes" in the dropdown field
Bind (see Figure 6).
Figure 6: Bind device g064464e
15. Click on the [Write] button in the toolbar to write the altered configura-
tion in the module.
You have now allocated a master to the Bluetooth
®
slave (Slave ! Master).
16. Under navigation in the Operation Mode field, choose the real-time mode
using the [Communication (Realtime)] button.
17. Proceed as in section 2.2.2 to create a link from the side of the master as
well (Master ! Slave).
