WAGO-I/O-SYSTEM 750 Application example: Starterkit880_App1_FUP.pro 41
750-880 ETHERNET Programmable Fieldbus
Quickstart Reference
Version 1.0.0
In the sixth Network, the visualization button [USR-LED] is assigned a color as a
function of "wIndex." This ensures that the [USR-LED] button has the same color
in the display as the physical USR-LED for the fieldbus controller. This value is
assigned via a multiplexer (MUX).
Figure 43: Network 6 (USR-LED)
Table 8: Button Color Allocation [USR-LED]
"wIndex"
"wIndex"
"wIndex"
0
0
0
1
1
1
2
2
2
3
3
3
