WAGO-I/O-SYSTEM 750 XTR Fieldbus Communication 201
750-352/040-000 FC ETHERNET G3 XTR
Manual
Version 1.3.0
Instance 0 (Class Attributes)
Table 187: Port class (F4
hex
) – Class
Attribute ID
Acces
s
Name
Data type
Description
Default value
1
Get
Revision
UINT
Revision of this object
1 (0x0001)
2
Get
Max Instance
UINT
Max. number of instances
1 (0x0001)
3
Get
Num Instances
UINT
Number of current ports
1 (0x0001)
8
Get
Entry Port
UINT
Instance of the port object
where the request arrived.
1 (0x0001)
9
Get
All Ports
Array of
Struct
UINT
Array with instance attributes
1 and 2 of all instances
0 (0x0000)
0 (0x0000)
4 (0x0004)
2 (0x0002)
Instance 1
Table 188: Port class (F4
hex
) – Instance 1
Attribute ID
Acces
s
NV
Name
Data type
Description
Default value
1
Get
V
Port Type
UINT
-
4 (0x0004)
2
Get
V
Port Number
UINT
CIP port number
2 (0x0002)
(EtherNet/IP)
3
Get
V
Port Object
UINT
Number of 16 bit
words in the
following path
2 (0x0002)
Padded
EPATH
Object, which
manages this port
0x20 0xF5
0x24 0x01
(equals TCP/IP
Interface Object)
4
Get
V
Port Name
SHORT_
STRING
Port name
“”
7
Get
V
Node Address
Padded
EPATH
Port segment (IP
address)
Depends on IP address
Common Services
Table 189: Port class (F4
hex
) – Common service
Service code
Service
available
Service-Name
Description
Class
Instance
01
hex
Yes
Yes
Get_Attribute_All
Supplies contents of all attributes
0E
hex
Yes
Yes
Get_Attribute_Single
Supplies contents of the appropriate attribute
