WAGO WAGO-I/O-SYSTEM 750 XTR User Manual

150 Fieldbus Communication WAGO-I/O-SYSTEM 750 XTR
750-352/040-000 FC ETHERNET G3 XTR
Manual
Version 1.3.0
11.1.2.6.1 MIB II Description
Pos: 90.4 /Serie 750 (WAGO-I/O-SYST EM )/F unk tio nsbe schr eib ung /Fel db usk om muni kati on/ SNM P (M IB) /SNM P ( Sim ple Ne twor k Ma nag eme nt P rot okol l) - Bes chr eib ung der M IB I I o hne Ver weis @ 18\ mod_1392815819948_21.docx @ 145911 @ @ 1
MIB II acc. to RFC1213 is divided into the following groups:
Table 65: MIB II groups
Group
Identifier
System Group
1.3.6.1.2.1.1
Interface Group
1.3.6.1.2.1.2
IP Group
1.3.6.1.2.1.4
IpRoute Table Group
1.3.6.1.2.1.4.21
ICMP Group
1.3.6.1.2.1.5
TCP Group
1.3.6.1.2.1.6
UDP Group
1.3.6.1.2.1.7
SNMP Group
1.3.6.1.2.1.11
Pos: 90.5 /Dokumentation allgemei n/Gliederungselemente/---Sei te nwe chsel --- @ 3\mod_1221108045078_0.docx @ 21810 @ @ 1
Pos: 90.6 /Serie 750 (WAGO-I/O- SYST EM) /F unkti ons bes chr eib ung /Fel dbus ko mmu nik ati on/SN M P (MI B)/ SNM P (Si m ple N et wor k Ma nag eme nt Pr oto koll ) - Stan dard- Tra ps (Ü ber schr ift 5) @ 7\ mod_1270703854440_21.docx @ 54954 @ 5 @ 1
11.1.2.6.2 Traps
Pos: 90.7 /Serie 750 (WAGO-I/O-SYST EM )/F unkti ons besc hrei bu ng/F el dbus kom muni kati on /SNM P ( MI B)/SN MP (Si mpl e Ne twor k M anag em ent Pro tok oll) - St andar d-T raps ( Einl eitu ng) @ 7\ mod_1270721636553_21.docx @ 54977 @ @ 1
Standard Traps
For specific events, the SNMP agent will independently send one of the following
messages without polling the manager.
Pos: 90.8 /Serie 750 (WAGO-I/O-SYST EM )/F unk tio nsbe schr eib ung /Fel db usk om muni kati on/ SNM P (M IB) /SNM P ( Sim ple Ne twor k Ma nag eme nt P rot okol l) - Hin weis: Er eig nis mel dung en i m W BM frei ge ben! V1, 2c , 3 @ 7\ mod_1270721741999_21.doc x @ 54980 @ @ 1
Enable event messages (traps) in the WBM!
Initially enable the event messages in the WBM in menu “SNMP” under “Trap
Enable”. Traps in version 1, 2c and 3 may be activated separately.
Pos: 90.9 /Serie 750 (WAGO-I/O- SYST EM) /F unkti ons bes chr eib ung /Fel dbus ko mmu nik ati on/SN M P (MI B)/ SNM P (Si m ple N et wor k Ma nag eme nt Pr oto koll ) - Stan dard- Tra ps @ 6\mod_1264588370404_21.docx @ 48822 @ @ 1
The following messages are triggered automatically as traps (SNMPv1) by the
fieldbus coupler/controller:
Table 66: Standard Traps
TrapType/TrapNumber/OI
D of the provided value
Name
Event
TrapType = 0
ColdStart
Restart the coupler/controller
TrapType = 1
WarmStart
Reset via mode selector switch (only
for controller)
TrapType = 3
EthernetUp
Network connection detected
TrapType = 4
AuthenticationFailure
Unauthorized (abortive) MIB
access
TrapType = 6/
ab Trap-Nummer 25
benutzerspezifisch
enterpriseSpecific
Enterprise-specific messages and
function poll in the PFC program
starting with enterprise trap number 25
Pos: 91 /Doku ment ation all gemei n/Gli eder ungsel eme nte/---Seit en wechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1

WAGO WAGO-I/O-SYSTEM 750 XTR Specifications

General

Product Type	I/O System
Series	750 XTR
Protection Class	IP20
Number of Modules	Up to 64
Power Supply	24 V DC
Relative Air Humidity	95 % (non-condensing)
EMC Immunity to Interference	EN 61000-6-2
Operating Temperature	-40°C to +70°C
Bus System	Fieldbus independent
Shock Resistance	15g
EMC Emission of Interference	EN 61000-6-4
Approvals	ATEX, IECEx
Connection Technology	Spring-loaded terminals
Number of Channels	Varies by module
Mounting Type	DIN Rail
Certifications	ATEX
