36 System Description WAGO-I/O-SYSTEM 750 XTR
750-352/040-000 FC ETHERNET G3 XTR
Manual
Version 1.3.0
Pos: 19.1 6. 38 / Seri e 75 0 ( WAGO -I/O-S Y STEM) /S yste mbes chr ei bung /V ersor gu ng/Er gä nzen de Eins p eise vorsc hr ift en XTR ( 750- 352/ 040- 000) @ 1 8\mod_1396457757102_21.doc x @ 150568 @ 3 @ 1
3.6.5 Supplementary Power Supply Regulations
The WAGO-I/O-SYSTEM 750 XTR can also be used in shipbuilding applications
and onshore/offshore installations (e.g., platforms, loading facilities), as well as in
telecontrol applications. This is possible via certification under the standards of
leading agencies such as Germanischer Lloyd and Lloyds Register.
For standard-compliant application in substation instrumentation and control,
telecontrol systems, railway technology or shipbuilding certified operation, field-
side power supply filter 750-624/040-00x or power supply filter 750-626/040-000
are generally to be used for XTR module groups.
Table 8: Filter modules for 24 V power supply
24 VDC HI
XTR
Supply Filter; 24 VDC; higher isolation;
extreme:
System and field supply with filtering (24 V,
0 V), i.e., fieldbus coupler/controller and
System Power Supply 24 VDC XTR
Filter 24 VDC
Field Side Supply Filter (Surge); 24 VDC;
higher isolation; extreme:
24 V field supply with filtering
Filter 24 VDC
HI NC XTR
Field Side Supply Filter (Surge); 24 VDC;
higher isolation; without power jumper
contacts; extreme:
24 V field supply with filtering
Therefore, the following power supply requirements must be observed:
The 24 V system power supply for the fieldbus coupler/controller must be filtered
and protected against overvoltage. Therefore, the power must be supplied via
power supply filter 750-626/040-000.
The electronic power supply must only be connected via a slow blow 2 A fuse.
The 24 V field power supply systems must be protected against overvoltage.
Therefore, the power must be supplied via field-side power supply filter
750-624/040-00x or power supply filter 750-626/ 040-000.
For this potential group, only the supply module 750-612/040-000 is required for
a 230 V field power supply.
