12.2.1 Digital Input Modules
The digital input modules provide a process value of one bit per channel, which
indicates the status of the respective channel. These bits are mapped into the
input process image.
Some digital input modules have an additional diagnostic bit per channel in the
input process image. The diagnostic bit detects faults (e.g., wire breakage,
overloads and/or short circuits).
If analog input modules are in the node, the digital data is grouped in bytes and
added to the analog input data in the process image.
12.2.1.1 2-Channel Digital Input Modules
Table 255: 2-Channel Digital Input Modules
Input Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Data bit
DI 2
Channel 2
Data bit
DI 1
Channel 1
12.2.1.2 8-Channel Digital Input Modules
Table 256: 8-Channel Digital Input Modules
Input Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Data bit
DI 8
Channel 8
Data bit
DI 7
Channel 7
Data bit
DI 6
Channel 6
Data bit
DI 5
Channel 5
Data bit
DI 4
Channel 4
Data bit
DI 3
Channel 3
Data bit
DI 2
Channel 2
Data bit
DI 1
Channel 1
12.2.1.3 16-Channel Digital Input Modules
Table 257: 16-Channel Digital Input Modules
Input Process Image
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Data
bit
DI 16
Chan
-
nel 16
Data
bit
DI 15
Chan-
nel 15
Data
bit
DI 14
Chan-
nel 14
Data
bit
DI 13
Chan-
nel 13
Data
bit
DI 12
Chan
-
nel 12
Data
bit
DI 11
Chan
-
nel 11
Data
bit
DI 10
Chan
-
nel 10
Data
bit
DI 9
Chan-
nel 9
Data
bit
DI 8
Chan-
nel 8
Data
bit
DI 7
Chan-
nel 7
Data
bit
DI 6
Chan-
nel 6
Data
bit
DI 5
Chan-
nel 5
Data
bit
DI 4
Chan-
nel 4
Data
bit
DI 3
Chan
-
nel 3
Data
bit
DI 2
Chan-
nel 2
Data
bit
DI 1
Chan-
nel 1

WAGO WAGO-I/O-SYSTEM 750 XTR Specifications

General

Product Type	I/O System
Series	750 XTR
Protection Class	IP20
Number of Modules	Up to 64
Power Supply	24 V DC
Relative Air Humidity	95 % (non-condensing)
EMC Immunity to Interference	EN 61000-6-2
Operating Temperature	-40°C to +70°C
Bus System	Fieldbus independent
Shock Resistance	15g
EMC Emission of Interference	EN 61000-6-4
Approvals	ATEX, IECEx
Connection Technology	Spring-loaded terminals
Number of Channels	Varies by module
Mounting Type	DIN Rail
Certifications	ATEX
