Page #8 background imageLoading...
Page #8 background image
Specications
4
MODEL H27i
TRANSAXLE (continued)
Neutral Transmission Release by Manual Dump Valve
Final Drive Direct Drive Axle from Transaxle
Transmission Fluid
Factory Service 20W50 MultiViscosity Motor Oil (Minimum SL Grade Oil)
Transmission Oil Capacity  oz (L) 77 (2.3)
Transmission Cooling Cooling Fan Mounted on Drive Pulley
Oil Filter HydroGear
®
P/N 52114 (Walker P/N 20266)
Ground Travel Speed
Forward MPH (km/h)
Reverse MPH (km/h)
010 (016) Innitely Variable
05 (08) Innitely Variable
BLADE DRIVE
PTO Shaft Sliding Spline Shaft with Two (2) HighSpeed UJoints
(Quick Disconnect)
Blade Drive Clutch and Brake Manual Belt Tightener Clutch and Band Brake
[Stops Blades within Five (5) Seconds of Disengagement]
TIRE SIZE
Deck Caster Wheel 13 x 4.506 (Pneumatic 6Ply)
Drive 22 x 10.5012 (4Ply LowProle)
Tailwheel 13 x 4.506 (Pneumatic 6Ply)
TIRE PRESSURE PSI (KPA)
Deck Caster Wheel 20 (137)
Drive 15 (103)
Tailwheel 20 (137)
DRIVE BELTS
Engine PTO Walker P/N 2230 (Set of 3)
Ground Drive Walker P/N 22481
SEAT Full Spring Suspension with Dampening and Adjustments for Back
Angle, Lumbar Support, and Operator Weight. Standard with Ad
justable/Retractable Armrests.
FRAME/BODY CONSTRUCTION
Frame All Welded Unitized Steel Chassis
Body 14 Gauge Steel
Deck 11 Gauge Steel
