Walker MBK23 - Component Identification

Component Identication
7
Front View and Right Side View
NOTE: Control Identication
shown in Operating
Instructions section.
Negative (-)
Battery Cable
Tilt-Up Hook
(Not Visible)
Deck Discharge Shield
Deck
Caster Wheels
Counterweight Springs and
Protective Covers
Positive (+)
Battery Cable
Deck Lift Handle
(Cutting Height Adjustment)
Deck Support Arm
(Not Visible)
Deck Support
Arm
Deck Support
Pins and Height
Adjustment
Hitch Pins
Tilt-Up
Deck Handle
Tilt-Up Latch
Footrests
Footrests
Oil Pressure
Warning Horn
(Not Visible)
Forward Speed
Control (FSC)
Friction
Adjustment
Body Tilt-Up Latch
(Not Visible)
