Walker MBK23 - Cylinder Head Cooling Fins

Maintenance Instructions CLEANING
47
Cylinder Head Cooling Fins
It is essential for performance and longevity of the
air-cooled engine to keep the cylinder head cooling
ns clean and free of obstruction. After every 8
hours of operation, check the performance of the
cooling system by starting the engine, holding a
hand adjacent to the cylinder head, and feeling the
cooling airow. If there is little or no airow, clean
the cooling ns as follows:
DANGER
Make sure to keep hands clear of exhaust
pipe, mufer, and moving parts when
checking airow.
Check Airow
with Hand
Cooling System Airow
Every 100 hours, inspect and clean the cooling ns
(more often when operating in extremely dusty, dirty
conditions). Remove the two (2) cooling n access
panels in the engine shroud and clean the cooling
ns and external surfaces using compressed air.
Make sure to reinstall the access panels before
oper ating the engine.
IMPORTANT: Yearly, it is good maintenance prac-
tice to remove the engine cooling shroud and clean
the cylinder head cooling ns thoroughly to prevent
overheating and extend engine life. Make sure cool-
ing shroud is reinstalled properly. This procedure
will require removing the engine from the chassis.
Engine Cooling
Fin Access Panels
Kohler Engine
Shroud
Engine Air
Intake Screen
Engine Air Intake Screen
and Cooling Fin Access Panels
