Maintenance Instructions REPLACING/REPAIRING
Fuel Filter
DANGER
Gasoline is extremely ammable and can
be highly explosive. To minimize danger:
• Before servicing the fuel system:
1) Disconnect the spark plug leads.
2) Disconnect the negative (-) battery ca-
ble from battery.
• Use only an approved fuel container for
gasoline.
• DO NOT allow open ames or sparks
near the machine while performing main-
tenance or refueling; DO NOT smoke
while working with fuel.
• Wipe up spilled gasoline immediately
and completely.
Model MBK23 is equipped with a 10 micron in-line
fuel lter between the fuel tank and the fuel pump
module. Replacement of this lter is recommended
every 200 hours of operation or more frequently
under extremely dusty or dirty conditions.
In-Line
Fuel Filter
Fuel Filter Location
IMPORTANT: Replace the fuel lter only in a clean
area where the fuel line and connections will not be
contaminated by any dust and dirt.
1. Expand and slide clamps on either side of the
lter away from lter and pull fuel lines off lter.
2. Replace lter, making sure that the arrow on the
lter is aligned with the fuel ow through the
lter.
3. Verify that the fuel lines and clamps are secure-
ly attached, and that no fuel leaks are present.
