● When using a side discharge mower deck, the
side discharge deector shield must not be re-
moved and must be kept in the lowest possible
position to deect grass clippings and thrown
objects down ward. Orient the side discharge
away from side walks or streets to minimize
cleanup of clippings. When mowing close to
obstacles, orient the side dis charge away from
obstacles to reduce the chance of damage to
property by thrown objects.
Discharge
Shield
Side Discharge Deector
Shield in Lowest Position
● When operating on a slope, reduce speed and
use caution to start, stop, and maneuver. Avoid
sharp turns or sudden changes in direction. The
maximum recommended slope operating
angle is 15 degrees or 27% grade.
8600-9
60 lb·ft ( 81 N·m )
8600-14
14 in.
15°
52 in.
Maximum Recommended
Slope - Do Not Operate
on Steep Slopes
Maximum Recommended Slope
DANGER
Do not mow or dump grass within 5 feet
(1.5 meters) of an embankment or retaining
wall with drop o.
No Driving Zone
5 FT
MINIMUM
