Walker S14i - Operating Instructions; Dumping the Catcher

Operating Instructions
40
GHS Flow and Components
Collection
Mower Deck
PTO
Clutch
Exhaust Screen
(Removable)
Catcher
Door Spring
(Not Visible)
Actuator
Rod
Powerl
®
Drive Motor
Grass-Pak
®
Vane Switch
“Full” Signal
Horn
Catcher
Door
Grass
Catcher
Catcher
Air Exhaust
Powerl
®
Delivery Spout
Dump
Handle
Catcher Delivery
Chute
Body Chute
Assembly
Blower
Deck
Discharge Chute
Shear Bolt
PTO and Blade
Gear Drive
GRASS HANDLING SYSTEM (GHS)
GHS Model Only
