Walker T Series User Manual

Component Identication
9
Top View (Engine Compartment)
Fuel Tank
Mufer
Radiator
Guard
Exhaust Grass
Shield
Radiator Hose to
Coolant Recovery Tank
Radiator Cap
Throttle Linkage
(Not Visible)
Exhaust Pipe
Fuel Line to Engine
(High Pressure)
Oil Dipstick/
Oil Fill
Radiator
Rubber Bumper
(Body Support)
Electronic Control
Unit (ECU)
GHS Blower
RH Hydrostatic
Transmission
Neutral Safety
Switch
Negative (-)
Battery Cable
Battery
LH Transmission
Lockout Lever
Positive (+)
Battery Cable
30 Amp
Circuit Breaker
PTO
Clutch Lever
RH Transmission
Lockout Lever
Air Intake Hose
EVAP Line
Fuel Return Line
Roll Over Valve
Air Filter
Restriction Gauge
Air Cleaner
Cover
Donaldson
Air Cleaner
Recovery
Coolant Tank
Fuel Filter
(Not Visible)
Overow
Hose
Air Intake
Plenum
LH Hydrostatic
Transmission
Fuel Gauge
Precleaner
Tube
Jackshaft
PTO Gearbox
Dipstick
RH Steering Lever
Spring / Dampener
LH Steering Lever
Spring / Dampener
High Speed
Radiator Fan Switch
Turbine
Precleaner
