9
(888) 253-0777
If the sides tilt up, then loosen the blue strap
on the front harness over the dog’s back, and
tighten up the red bottom strap.
If the extenders tilt down, loosen the front
harness red bottom strap 2", and then
tighten the blue strap 2" over the dogs
back to raise extenders up and parallel to
the ground.
The side extenders should be parallel to the
ground and in the middle of the dog’s body.
Is the Length Correct?
The end of the extenders (black cap) should be positioned at the
center of the dog’s shoulder blades. The extenders should be touch-
ing the neoprene pads on the front harness and not pulling outward.
INCORRECT
INCORRECT
CORRECT
Adjusting the Length
Note: If you have the Front Wheel Attachment, remove the
extenders and skip to p.18.
The extenders are for length adjustments. The kit comes with one set.
To adjust the extenders, depress the snap button and move to
desired length.
26" Extenders
15" Extenders
