COMMANDER - installation guide en
DIMENSIONS & POSITIONING
Before selecting the mounting situation of your Wallbox Commander, please read the following tips and references:
A proper installation is absolutely necessary and lies outside of the scope of liability of Wallbox
12
According to the product standard, the charging station must be located at a height
between 1.30 m and 1.70 m. We recommend mounting the charging station at a height of 1.60 m.
Keep in mind that national regulations can limit this height.
It is compulsory to consider the following precautions:
The required mounting area for the Wallbox charging station is at least
250 x 150 mm (H x W).
Wallbox uses a simple framework of rails located underneath its body to
upgrade and embed new accessories. To avoid future interferences, it is
recommended to keep an extra 100mm below your device.
To keep the socket ergonomics, choose a mounting site that is comfortable
and extend a free 200mm on the right hand of the charger device to ensure
complete functionality.
When mounting the Wallbox Commander, the cable should easily reach the
charging port.
For a safe operation of your charging station, the recommended minimum
distances to other technical installations must be observed
TOOLS REQUIRED:
Phillips head screwdriver
Drilling machine plus 10mm tool
Cutter or razor for the wall cable,
