COMMANDER - installation guide en 8
PRODUCT DESCRIPTION 2/3
GENERAL
Model Name Commander Type 2
Mode Mode 3
Overall Dimensions (w/o connector) 220x150x135mm
Weight 4-6Kg. depending on cable length
Operating Temperature -25ºC to 45ºC
Storage Temperature -40ºC to 70ºC
CE marking
SPECIFICATIONS
Max Power 22 kW three phase
Input voltage 230VAC (1P), 400V AC (3P) ± 10%
Max. Current 32A, cable sizes up to 5x6mm²
Nominal Frequency 50Hz
Protection Class I
Degree of Protection IP54
Overvoltage Category CAT III
STATUS & USER INTERFACE
Screen dimensions 7inch (164,9x95,4mm,)
Touchscreen Model Capacitive
Resolution 800x480px
Communications Wi-Fi / Ethernet
Commander Type 1
Mode 3
220x150x135mm
4-6Kg. depending on cable length
-25ºC to 45ºC
-40ºC to 70ºC
IEC61851-1 , IEC61851-22
7,4kW one phase
230V, AC ± 10%
32A, cable sizes up to 5x6mm²
50Hz
I
IP54
CAT III
7inch (164,9x95,4mm,)
Capacitive
800x480px
Wi-Fi / Ethernet
IEC61851-1 , IEC61851-22
MECHANICAL
Installation
Cooling
Wall Mount
Natural Cooling
Wall Mount
Natural Cooling
SUMMARY INFORMATION
