USING SUPERNOVA
The charging process is standardised for all Supernova chargers, although some minor
dierences may exist depending on the site.
A Supernova charger consists of the following components:
L1
L2
L3
L4
L1
L2
L3
N
PE
PE
Charger Ambient Light
Threads for eye bolts
EV Cable 1 Exit*
Charger Status Light
EV Cable 1 Instrucions*
RFID reader
EV Cable 1 Status Light*
10” Touch Display
EV Cable 1 Holster*
EV Cable 1 Plug*
Air outtake
Access Key-Lock
Air intake
Product Label
*Equivalent for EV Cable 2 is located on the other side.
