Walther Systemtechnik VMS-02 User Manual

Rev. 1.4
Assembly Instructions – Full-Jet Valve VMS-02
Page 11 of 19
Walther Systemtechnik GmbH – D 76726 Germersheim
Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91
http://www.walther-2000.de – info@walther-2000.de
7.5 Inserting Gaskets and O-Rings
IMPORTANT
Gaskets and sealing kits can be damaged. Do not use any sharp-edged metal tools for remov-
ing or inserting gaskets!
If a complete sealing screw (pos. 4.0) with an inserted gasket set (pos. 3.0) is not available as a
replacement, the old gaskets must be removed and replaced with new ones. In order to do so, the sealing
screw must be thoroughly cleaned so that no particles of the previous spraying fluid impair the installation of
the new gaskets. The O-ring seats should be lightly greased with a lubricant (technical Vaseline). First insert
O-ring (pos. 4.2) into the rear hole of the sealing screw until it reaches the end. Then insert O-ring (pos. 3.1)
into the outermost groove. Insert the special form gasket (pos. 3.3) into the front seat. Since this form gasket
is not symmetrical, the side with the larger outer diameter must be inserted facing forwards, i.e. it must point
in the direction of the nozzle after the complete sealing screw has been installed. Slightly grease the sealing
screw (pos. 4.0) and insert it back into the valve body (pos. 2.0). Use a screwdriver to carefully push it
through the mounting thread together with the outer O-ring (pos. 3.1) without twisting it. Then screw the
sealing screw into the thread (gently tighten).
Do not use any metallic or sharp-edged aids or tools when you insert the O-rings and the special form
gasket. Despite all its outstanding sealing qualities, the special form gasket is a sensitive precision
component, which cannot tolerate impacts or pressure.
7.6 Routine Tasks
No.
Description
Cleaning
Lubricating
Inspecting
Additional tasks
Frequency
1.
connections
(tightness)
X
monthly
2.
nozzle
X
X
exchange if
damaged
monthly
3.
complete valve
X
check for wear
after 10 mio.
switching
operations
7.7 Spare Parts
IMPORTANT
Only use original spare parts from the manufacturer!
Wrong or defective spare parts from other manufacturers can damage the device. If other
than original spare parts of the manufacturer will be used, all obligations from the manufac-
turer or his sales partners, such as guarantees, service contracts etc will be forfeited without
further notice.
7.8 Customer Service / Support
Walther Systemtechnik GmbH
Hockenheimer Straße 3
D-76726 Germersheim
Deutschland
Telefon ++49(0)7274-7022-0
Telefax ++49(0)7274-7022-91
Email info@walther-2000.de
Internet www.walther-2000.de
