1.5.12 K-Series Kabin Pak – Pre-Wired (K70 & K90) – Key Components
1. Heat Exchanger
2. ‘Dual-Safe’ Thermostat
3. Heat Exchanger Baffles
4. Service Door
5. Service Door Cover
6. Riello RDB 2.2 Burner
7. Flue Opening
8. Heating Flow Connection
9. Heating Return Connection
1
23
5
4
6
7
8
9
1.5.13 K-Series Kabin Pak – Pre-wired (K120) – Key Components
1. Primary Heat Exchanger
2. Secondary Heat Exchanger
3. ‘Dual-Safe’ Thermostat
4. Secondary Exchanger
Inspection Lid
5. Primary Exchanger Baffles
6. Service Door
7. Service Door Cover
8. Riello RDB 2.2 Burner
9. Flue Opening
10. Heating Flow Connection x 2
11. Heating Return Connection
1
2
3
4
5
6
7
8
1110
10
9
