WarmFlow B-Series B70 - Dimensions

Page 18
2.2 Dimensions
2.2.1 B-Series Boilerhouse (70 & 90 Output Models)
JHGFEDCBAMODEL
B70 / B90 / B1 396 573 383 574 127 198 78 32 183
I
152
2.2.2 B-Series Boilerhouse (120 Output Model)
KJGEDCBAMODEL
B120 397 383 662 273 575 152 42 103
